Twitter| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler, Trader |
| Country of Origin | India |
| Type | Horizontal Lathe |
| Brand Name | OM |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Certification
ISO 9001:2015,CE Cerified
Material
Cast Iron
Phase
Three Phase
Color
Yellow
Condition
New
Driven Type
Electric
Warranty
1 Year
Automation Grade
Semi Automatic
Shape
Rectangular
Packaging Type
Carton Box, Metal Sheet Box, Wooden Box
Speciality
Easy To Use, High Efficiency, Reliable, Robust Construction
Finishing
Chrome Finish
Machine Weight
100-1000 Kg
Swing Over Bed
1000 Mm
Bed Width
550 Mm
Height of Centre
500 mm
Spindle Bore
127 mm
Distance Between Centre
3000 mm
Maximum Swing in Gap
1600 mm
Tail Stock Spindle Taper Bore
MT-5
Port
Any Indian Port
Payment Terms
L/C, D/A, D/P, T/T, Western Union, Other
Delivery Time
Ready Stock
Packaging Details
As Per Customer Requirement
Lathe Machine Manufacturer
Oil Country Lathe Machine in India
Oil Country Lathe Machine in Batala
OM Brand - Heavy Duty Oil Country Lathe Machine 500 mm
We are one of the leading manufacturers and suppliers of Heavy Duty Oil Country Lathe Machine. The offered planner lathe machine is made from high tensile steel, which is duly hardened for performing under high mechanical stress. Our supplied planner lathe machine is capable of producing plane surfaces, solids of revolution and helices.Features:
- Induction hardened spindle design
- Flame hardened bed ways
- Longer functional life
Technical Specification
| Particular | OMHL – 20 | OMHL – 22 | OMHL – 24 | OMHL – 26 | OMHL – 28 | OMHL – 30 | OMHL – 32 | |||||||
| INCH | MM | INCH | MM | INCH | MM | INCH | MM | INCH | MM | INCH | MM | INCH | MM | |
| Height of Center | 20” | 500 | 22” | 550 | 24” | 600 | 26” | 650 | 28” | 700 | 30” | 750 | 32” | 800 |
| Width of Bed | 22” | 550 | 26” | 650 | 28” | 700 | 30” | 750 | 32” | 800 | 34” | 850 | 36” | 900 |
| Distance Between Centre | 3000 MM TO 20000 MM / 120 INCH TO 780 INCH | |||||||||||||
| Swing over Bed | 40” | 1000 | 44” | 1100 | 48” | 1200 | 52” | 1300 | 56” | 1400 | 60” | 1500 | 64” | 1600 |
| Swing in Gap | 64” | 1600 | 68” | 1700 | 72” | 1800 | 76” | 1900 | 80” | 2000 | 84” | 2100 | 88” | 2200 |
| Spindle Bore | 127 MM TO 625 MM / 5 INCH TO 25 INCH | |||||||||||||
| Morse Taper of Sleeve | MT – 5 | |||||||||||||
| Main Power | 10 H.P | 10 H.P | 10 H.P | 10 H.P | 15 H.P | 15 H.P | 15 H.P | |||||||
